25.6V 300Ah Deep Cycle Forklift Battery High Energy Density Lithium Battery

25.6V 300Ah Deep Cycle Forklift Battery High Energy Density Lithium Battery

deep cycle li ion battery forklift

300Ah Deep Cycle Forklift

25.6v li ion battery forklift

Place of Origin:

China

Brand Name:

YouNatural

Model Number:

YNT24-150-53

Contact Us

Request A Quote
Product Details
Product Name:
Deep Cycle Forklift Battery 25.6V 300Ah
Voltage:
25.6V
Capadity:
300Ah
Cell Chemistry:
Lithium
Weight Kg:
402
Dimension Mm:
799x217x795
Truck Model:
OPX 20-25
Payment & Shipping Terms
Minimum Order Quantity
1Set
Price
Negotiation
Payment Terms
L/C, T/T, Western Union, MoneyGram
Supply Ability
2000 Pieces per Day
Product Description

25.6V 300Ah Deep Cycle Forklift Battery High Energy Density Lithium Battery

Features



·Deep cycle lithium-ion forklift battery is a type of rechargeable battery that uses lithium-ion technology to power electric forklifts.



·Opportunity charging: Deep cycle lithium-ion forklift batteries can be opportunity charged, which means they can be charged during breaks in work without affecting their lifespan. This can help to extend the battery life and reduce the need for battery changes or full recharges.


·Size and weight: Deep cycle lithium-ion forklift batteries are smaller and lighter than lead-acid batteries, which can help to improve the maneuverability and efficiency of forklifts. This canalso allow for more space in the forklift for other equipment or goods.


·Cost: While the upfront cost of lithium-ion forklift batteries may be higher than lead-acid batteries, the longer lifespan and lower maintenance costs can result in significant cost savings over time. Additionally, the faster charging and opportunity charging features can lead to increased productivity and efficiency.





Specification



Model YNT24-300-53
Nominal Voltage 25.6V
Nominal Capadity 300Ah
cell Chemistry Lithium
Charging curent A 150
Charging curent limitA 250
Max discharging curent 600A
CAN Configurable
RS485 Configurable
Dimension mm 799x217x795
Weight kg 402
Warranty 3years
Truck model OPX 20-25



Product display



25.6V 300Ah Deep Cycle Forklift Battery High Energy Density Lithium Battery 0





Certifications
UL, CE, UN38.3, MSDS, IEC and other international certifications
25.6V 300Ah Deep Cycle Forklift Battery High Energy Density Lithium Battery 1


About US



25.6V 300Ah Deep Cycle Forklift Battery High Energy Density Lithium Battery 2

An Innovative Manufacturer and Trusted Partner

Located in Maryland, USA and Shanghai, China, we are committed to promoting the development of green new energy. We have more than 20 years’ industry experience and professional technicians, dedicated to providing customized energy storage system solutions. We are mainly engaged in lithium-ion battery product series: single cell lithium-ion, battery pack, photovoltaic panel, indoor and outdoor solar energy storage power system, etc.



25.6V 300Ah Deep Cycle Forklift Battery High Energy Density Lithium Battery 3
Top Service High Quality OEM/ODM Customized After Sales
We will test all products and send test videos or pictures to customer for confirmation. Our products have obtained UL, CE, UN38.3, MSDS, IEC and other international certifications.
More than 20 years industry experience, provide customized energy storage system
solutions.
We are committed to providing you with high-quality, reliable products and services.





FAQ

1: How can we guarantee quality?
A: Always a pre-production sample before mass production; Always final Inspection before shipment.
2: What can you buy from us?
A: lithium-ion single cell, battery pack, photovoltaic panel, indoor and outdoor solar energy storage power system, portable energy storage power system, etc.
3: Can you have a sample order?
A: Yes, we welcome sample order to test and check quality.
4: What about the lead time?
A: Sample needs 10-15 days, mass production time needs 5-8 weeks, it depends on order quantity.
5: How about you payment and delivery items?
A: Payment items: By T/T, 50% for deposit, and balance all before shipment. For small amount, we also accept payment via PayPal, Western Union.
6: What kind of certificates could you provide for these batteries?
A: We have CE,CB,KC,MSDS,UN38.3 for most our current products, if It's custom-making design, usually no current certificates, we could apply for you if you need, but the related fees should be paid by your side, and if your order is big enough, certificate fees can be refunded.
